Total weight, kg 20500-20900
Engine type diesel
Number and arrangement of cylinders 6.
Engine displacement, cm3 6700
Engine power, kW (hp) 131 (176)
Estimated speed, rpm 1900
Bore and stroke 107×124
Engine manufacturer (brand) Cummins
Fuel system
Maximum speed, km/h 35
Dimensions
Ground clearance, mm 345
Wheelbase (track), mm 2800
Overall dimensions, mm (9500-9680) x2490x3180
Electrical equipment
Batteries (voltage/capacity), V/Ah 12/100
Refueling tanks
Fuel tank, l 310
Cooling system, l 35
Hydraulic system, l. 340
Hydraulic tank, l. 165
Operating characteristics
Digging depth, mm 5480-6380
Dumping height, mm 6670-7160
Wheels
Tires 10.00 – 20-16PR
Front/rear track wheels, mm 1874
Attachments
Bucket capacity, cubic meters. 0.6-1.34
Excavator Features
Rear Platform Swing Radius, mm 2800
Platform Rotation Speed, rpm 10.3
Digging Height, mm 9500-10000
Maximum Reach (per Ground Level), mm 9110-9960
Excavator Specifications
Blade Width x Height, mm 2490×610
Maximum Dam Depth/Lift, mm 125/445
