Payload, kg 3300 /

Total weight, kg 8070

Engine model 1004-40T (1004-42)

engine type diesel

Number and arrangement of rollers 4.

Engine power hp 85 hp.

Engine manufacturer (brand) Perkins

Gearbox

Transmission type mechanical

Fuel system

Maximum speed, km/h 35

Dimensions

Ground clearance, mm 370

Wheelbase (track), mm 2170

Overall dimensions, mm 5620x2360x3610

Maximum height of bucket suspension point, mm 3450

Refueling tanks

Fuel tank, l 160

Cooling system, l 23

Hydraulic system, l. 132

Operating characteristics

Digging depth, mm 70-100 / 4240

Dumping height, mm 2420

Wheels

Tires 10.5x18x10 / 18.4 / 15x26x12

Driving characteristics

Control type seated

Attachments

Working body type Bucket (front/rear)

Bucket capacity, cubic meters. 1.1-1.3 – 0.60

Bucket edge width, mm 2230/610

Fork/grip width x length, mm х1200
