Dimensions
Approximate Shipping Weight (Open Station; Cab)
FWD – Open: 2550 kg 5621 lb Cab: 3250 kg 7165 lb
Wheelbase – 2WD
2050 mm
Wheelbase – FWD
2050 mm
Specifications
Engine
Number of Cylinders
3
Cylinder Liners
Wet-Coiled
Rated Power
At 2100 rpm: 49.9 kW 67 hp
Rated PTO Power
At 2100 rpm: 36.5 kW 49 hp PTO
Displacement
2.9 l
Aspiration
Turbocharged
Description
John Deere PowerTech 3029
Capacities
Fuel Tank
Standard: Open: 68 L 18 US gal Cab: 82 L 21 US gal
Transmission
Clutch, Wet/Dry
Dry on 9F/3R SyncShuttle Wet on 12F/12R PowrReverser
Creeper Traction
Option on models with 9F/3R transmission
Shuttle
Optional
Transmission Type
Standard: 9F/3R SyncShuttle Optional: 12F/12R PowrReverser
Tires
Turning Radius with Brakes
2WD: 3.1 m 10.6 ft
Front
2WD: 7.5-16 R1 MFWD: 9.5-24 R1
Rear
2WD: 16.9-28 R1 MFWD: 16.9-28 R1
Turning radius without brakes
2WD: 3.5 m 11.5 ft, in.
